Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
19 OF 168
19
High speed motor end
bearing temperature
sensor
measure the high speed motor end bearing
temperature
Standard for 19XR6/7
High speed comp end
bearing temperature
sensor
measure the high speed compressor end
bearing temperature
Standard for 19XR6/7
Comp thrust bearing oil
temperature sensor
Measure the compressor thrust bearing oil
temperature
Standard for
19XR2~E/V/D
1st Stage Bearing
Temp
Measure the 1
st
stage bearing temperature
Standard for 19DV
2nd Stage Bearing
Temp
Measure the 2
nd
stage bearing temperature
Standard for 19DV
Bearing Ref Supply
Temp
Measure the bearing ref supply temperature
Standard for 19DV
Motor winding
temperature sensors
The 3 sensors measure the temperature of
compressor motor windings
Standard for
19XR2~E/V/D,
19XR6/7 and 19DV
19XR2~E/V/D and
19DV only has 1
sensor.
Oil sump temperature
sensor
measures the compressor sump
temperature of oil
Standard for
19XR2~E/V/D and
19XR6/7
Oil supply temperature
sensor
measures the oil temperature in the oil
discharge piping
Standard for
19XR2~E/V/D and
19XR6/7
The temperature sensor range is -40 ~ +245°F.
