Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
28 OF 168
28
IOB3
DO1
Chiller Status(Discrete)
User option
IOB3
DO2
Chiller Alert Relay
User option, 24VAC
output, recommend
with external power
supply
IOB3
DO3
Chilled Water Pump
User option
IOB3
DO4
Condenser Water Pump
User option
IOB4
AI1
IOB4
AI2
IOB4
AI3
[If Water Pressure Option is PD TRD
(transducers)]
Evap Enter Water Volts
[If Water Pressure Option is PD TRM
(transmitter)]
Chilled Water Pres Drop
User option
IOB4
AI4
[If Water Pressure Option is PD TRD
(transducers)]
Evap Leave Water Volts
[If Water Pressure Option is PD TRM
(transmitter)]
Cond Water Pres Drop
User option
IOB4
AI5
[If Water Pressure Option is PD TRD
(transducers)]
Cond Enter Water Volts
User option
IOB4
AI6
[If Water Pressure Option is PD TRD
(transducers)]
Leaving Cond Water Pressure
User option
IOB4
AI7
IOB4
AI8
Evap Water Flow Measurement
User option, 4~20mA
IOB4
AI9
Cond Water Flow Measurement
User option, 4~20mA
IOB4
AI10
IOB4
AI11
IOB4
AO1
Chilled Water Pump (Variable)
IOB4
AO2
Condenser Water Pump (Variable)
IOB4
AO3
Tower Fan (Variable)
IOB4
DI1
IOB4
DI2
Power Request Feedback
Marine option
IOB4
DI3
Customer Alert
User option
IOB4
DI4
Free Cooling Start Switch
User option
IOB4
DO1
Free Cooling Mode
User option
IOB4
DO2
Power Request Output
Marine option
IOB4
DO3
Tower Fan High
User option
IOB4
DO4
Tower Fan Low
User option
