Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
82 OF 168
82
High CURRENT
override
PERCENT LINE
CURRENT
PERCENT LINE
CURRENT >
100%
or RECTIFIER
OVERLOAD (Only
for 32VS VFD) >
100%
PERCENT LINE
CURRENT >
105%
(If 32VS VFD is
installed,
PERCENT LINE
CURRENT or
RECTIFIER
OVERLOAD >
102%)
PERCENT LINE
CURRENT <=
100%
Low Discharge
Superheat
Override
Discharge
Superheat
< DSH
REQUIRED + 1
< DSH
REQUIRED – 3
> DSH
REQUIRED + 2
Low Source
Temp Protection
Override
Leaving chilled
water temperature
(Heating mode)
<
LWT
Protection
Setpoint
(Protective
Limit Config)
–
2F
>
LWT
Protection
Setpoint
(Protective
Limit Config)
–
2F
