CAS CI-2001A - Test Mode Operations; Entering Test Mode; Test Menu Overview

1
TEST MODE
1. HOW TO ENTER
Turn on the power while pressing the "PRINT" key and TEST menu starts.
(CI-2001A/B kg/lb Version)
Turn on the power while pressing the "*" key and TEST menu starts.
(CI-2001A/B kg only Version)
2. AVAILABLE KEYS
▲
Increase the first place set value to 1
◀
Move to the left by 1 place of the set value.
*
Initialize Setting value.
ENTER
Move into next menu. (CI-2001A)
LIGHT
Move into next menu. (CI-2001B)
3. TEST MENU (TEST 1 - TEST 5)
TEST 1 KEY TEST
TEST 2 DISPLAY TEST
TEST 3 Loadcell test and A/D conversion TEST
TEST 4 Serial interface test (RS-232)
TEST 5 Printer test
TEST 1
■ FUNCTION : KEY TEST
KEY DISPLAY DESCRIPTION
ENTER(LIGHT) :
Next Menu
Other Keys :
Perform TEST
TEST 1 condition.
Press the key to be test and the no.
and code of the key is displayed.
8
