CAS CI-2001A - Err 24: Small Loadcell Output; Err 25: Large Loadcell Output; Err 26: Large Loadcell Output (Zero)

37
Err 24
▣ Reason
The load cell output is too small at SPAN calibration.
☞ Trouble shooting
Setting of current resolution is not possible due to the error in load cell. Proceed
calibration again with less resolution.
Loadcell Sense Voltage
for 5V Excitation Voltage
Recommended Resolution
2 mV 1/1,000
4 mV 1/2,000
10 mV 1/5,000
Err 25
▣ Reason
The load cell output is too large at SPAN calibration.
☞ Trouble shooting
Setting of current resolution is not possible due to the error in load cell. Proceed
calibration again with less resolution.
Err 26
▣ Reason
The load cell output is too large at ZERO calibration.
☞ Trouble shooting
Check whether the platform empty.
Proceed calibration again after checking in A/D TEST mode.
