CAS CI-2400BS - Sealing Procedure for Weighing Indicator

13
Connection ND-T102, ND-192 Printer
RXD
TXD
GND
3 Transmit Data
2 Receive Data
7 Signal Ground
9pin port(Female)
Serial port of ND-T102(THERMAL),
ND-192(DOT)
RS-232C port of CI-2400BS
Load cell Connection(EX+, EX-, SIG+, SIG-, GND)
EX+: Excitation voltage+, EX-: Excitation voltage-
SIG+: Sense voltage+, SIG-: Sense voltage-, GND: Shield ground
Connecting method
Ref 1. Each load cell manufacturer’s or model’s wire color could be different.
In that case, please note the following diagram.
Manufacturer’s wire colors
N0. 1 No. 2 No. 3 No. 4 No.5
(EX
) (EX ) (SIG ) (SIG ) (GND)
Red White Green Blue Shield
Red Black Green White Shield
Red Black Green White Shield
Red Black Green White Shield
Green Black White Red Yellow
Red Blue White Black Shield
Red Black Green White Shield
Red White Green Blue Yellow
Red Black White Green Shield
Red Blue White Black Yellow
Green Black Red White Shield
Green Black White Red
Yellow/Shield
Red Black Green White Shield
Company
CAS
KYOWA
INTERFACE
P.T
BLS
SHOWA
SHINKOH
TMI
TML
TFAC
HUNTLEIGH
RTI/RTE 5wires
RTI/RTE 7wires
Connector
