46
<Simple Command Mode Table>
Indicator
Reception
Function Indicator Response
dd RW CR LF
Request for weight
data
If this command is received, it sends the data in the designated
format. (sends the data in the designated format.)
dd MZ CR LF
Same as the Zero
key
If this command is received, it performs the Zero compensation is
performed and re-transmits dd MZ CR LF to the PC.
dd MT CR LF
Same as the Tare
key
If this command is received, it operates the tare and re-transmits
dd MT CR LF to the PC.
dd PN 00 CR LF
ID number input
(01~99)
If this command is received, it changes the ID number and re-
sends dd PN 00 CR LF to the PC.
Note 1. dd= Device ID (2byte), CR = 0X0D, LF: OX0A
Ex) If the Device ID is 10, dd is 0X31, 0X30
Note 2. If F25 is set to 5, transmit Device ID 1 byte as a Hex value.
Ex>
Device ID Input Signal
03 03
10 0A
99 63
PRT Communication
F26
Function Set the PRT Baud Rate
Display Signification
F26. 0 600 bps
F26. 1 1,200 bps
F26. 2 2,400 bps
F26. 3 4,800 bps
F26. 4 9,600 bps
F26. 5 19,200 bps
F26. 6 38,400 bps
F26. 7 57,600 bps
Set-up Range
(0 ~ 8)
F26. 8 115,200 bps
F27
Function Set the PRT – Output Mode
Display Signification
F27. 0 Do not send data
F27. 1 Transmit when stable / unstable (Stream Mode)
F27. 2 Transmit only when the weight is stable
Set-up Range
(0 ~ 3)
F27. 3 Transmit only when the Print key is pressed
