Set External Relay In/Output Function
(Relay Function)
F50
Function External Relay Input Set Function (function external relay input set)
Display COM1 COM2 COM3 COM4
F50. 0 Zero Tare / Clear Tare Net Weight Gross Weight
F50. 1 Zero Tare / Clear Tare Print
Gross / Net
Weight
F50. 2 Zero Tare / Clear Tare Hold Remove Hold
F50. 3 Zero Tare / Clear Tare
Hold / Remove
Hold
Print
F50. 4 Zero Tare Remove Tare Print
F50. 5 Zero Sub-total Grand-Total Print
F50. 6 Zero Tare / Clear Tare Start Stop
F50. 7 Zero Print Start Stop
F50. 8 Remove Tare Tare Start Stop
F50. 9 Gross Weight Net Weight Start Stop
F50. 10 Zero Print Start Stop
F50. 11 Zero Tare / Clear Tare Start / Stop Print
Set-up Range
(0 ~ 12)
F50. 12 Zero Tare / Clear Tare Judgment Print
Note. With the Tare / Clear Tare function, tare is only cleared if all the criteria are met.
Note. Forced Removal of Tare clears tare without meeting the required criteria .
F51
Function: Select Weighing mode (Relay Mode)
Display Sub- Display Description
1
Limit Mode 1
(Contact ‘A’ output of 4 steps)
2
Limit Mode 2
(Free Fall and Weighing judgment)
3
Packer Mode 1
(Contact ‘B’ output of 4 steps)
4
Packer Mode 2
(Free Fall and Weighing judgment)
5
Checker Mode 1
(5 steps judgment when weight is stable)
6
Checker Mode 2
(3 steps judgment when weight is stable)
7 Checker Mode 3 (Weight level)
8 Checker Mode 4 (Injection Management)
Set-up
Range
(0~9)
9
RELAY SET
1-9
Checker Mode 5 (Checking Weight)
To Next Page
