Relay Output OUT 1 OUT 2 OUT 3 OUT 4 OUT 5 OUT 6
1
Limit Mode 1
(Contact ‘A’ output
of 4 steps)
SP1 SP2 SP3 SP4 Finish Zero
2
Limit Mode 2
(Free Fall and
Weighing judgment)
SP1 SP2 Finish
Lowest
limit NG
Upper
limit NG
Zero
3
Packer Mode 1
(Contact ‘B’ output of
4 steps)
SP1 SP2 SP3 SP4 Finish Zero
4
Packer Mode 2
(Free Fall and
Weighing judgment)
SP1 SP2 Finish
Lowest
limit NG
Upper
limit NG
Zero
5
Checker Mode 1
(Judged when weight
is stable)
SP1 SP2 SP3 SP4
Over
Step 4
Zero
6
Checker Mode 2
(Judged when weight
is stable)
SP1
(LOW)
SP2
(H IGH)
SP3
(OK)
Lowest
limit NG
Upper
limit NG
Zero
7
Checker Mode 3
(Weight level)
SP1 SP2 SP3 SP4
Over
Step 4
Zero
8
Checker Mode 4
(Injection
management)
SP1
(LOW)
SP2
(H IGH)
SP3
(OK)
Lowest
limit NG
Upper
limit NG
Zero
9
Checker Mode 5
(Checking Weight)
SP1
(LOW)
SP2
(H IGH)
SP3
(OK)
Lowest
limit NG
Upper
limit NG
Zero
