CAS CI-502A - Option Series

`
6
4
Option Series
F70
Function Designate the Output Mode When BCD Out Option is in Use
Display Signification
F70 0 Positive Logic
Set-up Range
(0, 1)
F70 1 Negative Logic
F71
Function Zero Output Calibration when Analogout Option is in Use
Display Signification
Low-A , L 0.000 0.000 mA, 0 V
Low-A , L 4.000 4.000 mA, 2 V
Set-up Range
(0 ~ 24,000)
Low-A , L 4.015 4.015 mA, 2.007 V
F72
Function Maximum Output Calibration when Analog Out Option is in Use
Display Signification
HiGH-A , H 10.000 10.000 mA , 4.16 V
HiGH-A , H 20.000 20.000 mA , 8.33 V
Set-up Range
(0 ~ 24000)
HiGH-A , H 24.000 24.000 mA , 10 V
F73
Function Maximum Output Weight Value when Analog Out Option is in Use
Display Signification
CAPA-A , C 1000 Maximum output at 1000 kg
CAPA-A , C 2000 Maximum output at 2000 kg
Set-up Range
(0 ~ 99999)
CAPA-A , C 50.30 Maximum output at 50.30 kg
