12
5. Connection Description
A. Remote connector
B. Extra display / Control box port
Control box :
Pin1 Pin2 Pin3 Pin4 Pin5
HI OK LO
VCC（5V）
GND
Extra display:
Pin6 Pin7 Pin8 Pin9
GND RXD TXD
