— 23 —
No. Pin Name In/Out Pull-Up/Down Function To/From
64 CAS0UB O CAS signal for DRAM DRAM
65 CAS1LB O CAS signal for DRAM DRAM
67 CAS1UB O CAS signal for DRAM DRAM
68 CAS2LB O CAS signal for DRAM DRAM
69 CAS2UB O CAS signal for DRAM DRAM
70 CHKPRGB I Port Pad
71 LEDOFFB I LED cancel signal SW10
72 IRQB O IRQ0 signal to CPU CPU
73 NMI O NMI signal to CPU CPU
74 STATUS0 I STATUS0 signal from CPU CPU
75 CKRTC256 I RTCCLK signal from CPU CPU
77 MCLOCK I CKI0 signal from CPU CPU
78 BACKB I BACK signal from CPU CPU
79 ONB O ON signal CPU
80 RESETB O RESET signal to CPU CPU
81 ONENB O ONEN signal to CPU CPU
82 BREQB O REQ signl to CPU CPU
83 SCK O SCK1 signal to CPU CPU
84 FUNKEYIN4 I Up Function input Kyboard
85 FUNKEYIN3 I Up Function input Kyboard
87 FUNKEYIN2 I Up Function input Kyboard
88 FUNKEYIN1 I Up Function input Kyboard
89 FUNKEYIN0 I Up Function input Kyboard
90 ONSTATUSB I ONSTATUSB signal from CPU CPU
92 KBOUT8 O Key common signal Keyboard
93 KBOUT7 O Key common signal Keyboard
94 KBOUT6 O Key common signal Keyboard
95 KBOUT5 O Key common signal Keyboard
96 KBOUT4 O Key common signal Keyboard
97 KBOUT3 O Key common signal Keyboard
98 KBOUT2 O Key common signal Keyboard
99 KBOUT1 O Key common signal Keyboard
101 XCKOUT I/O Oscillator output Y3
102 XCKIN I Oscillator inut Y3
103 BATDTCT I Alkaline/NiMH detecting port SW3
104 KBOUT0 O Key common signal Keyboard
105 KBDIN0 I Up Key segment signal Keyboard
106 KBDIN1 I Up Key segment signal Keyboard
107 KBDIN2 I Up Key segment signal Keyboard
108 KBDIN3 I Up Key segment signal Keyboard
109 KBDIN4 I Up Key segment signal Keyboard
111 KBDIN5 I Up Key segment signal Keyboard
112 KBDIN6 I Up Key segment signal Keyboard
113 KBDIN7 I Up Key segment signal Keyboard
114 ONSWB I Up ON switch signal ON
115 MEMCLB I Memory clear signal RESET
116 LOCK I PCMCIA lock switch SW1
117 DOCKB I Cradle detector Detector (Q18)
118 BCVRB I Battery cover detecting port SW2
119 ACDTCTB I Up AC adaptor detect RS232C
121 AVCC2 I +3V source for Touch panel
122 TCPVRH I Reference voltage for A/D converter of TP Touch panel
123 TCPVRL I Reference voltage for A/D converter of TP Touch panel
124 VDETADIN I Power detecting signal Power
125 TCPIN2 I Analog signal input from TP Touch panel
