Boot
To boot the diagnostics, press RESET button while holding down keys Ctrl, CapsShift and ON. The main
menu of diagnostics is displayed after release.
Preparation
1 : A-10 or A-11 4 : RAM Card XC-110
2 : Alkaline batteries 5 : AC-adaptor
3 : Jigs of RS-JIG-232C and RS-JIG-3PIN 6 : Charger
7 : Rechargeable battery pack
Note: Be sure to keep separate back-up copies of all important data in A-10/A-11, because the
DISGNOSTICS make data corrupt.
Step
Operation Display Note
Boot
Press RESET button
while holding down keys
Ctrl, CapsShift and ON,
and then release Ctrl,
CapsShift and ON.
** Main Menu **
0 AUTO MODE
1 DISPLAY
2 TOUCH PANEL
3 MEMORY
4 SERIAL
5 POWER CONTROL
6 AUDIO
7 Others
CPROG Rev1.00
Main Battery
Check
7
** Others **
1 Switch
2 PCMCIA (implement)
3 PCMCIA (RAM card)
4 PCMCIA (WAIT)
5 Keyboard RANDOM
6 Keyboard SERIAL 1
7 Keyboard SERIAL 2
8 EL
1
VDET1 OFF
VDET2 OFF
VDET1R OFF
VDET2R (indefinite)
VDET3 OFF
VDETS ON
Recharge OFF
CHKPRG OFF
AC Adapter NOT USED
Cover CLOSED
CardLock CLOSED
Cradle NOT STAY
Make sure that the VDET1
is OFF. If ON, replace bat-
teries with new ones and
try again.
Remove backup battery.
Press ON.
Press RESET while hold-
ing down Nortification
Button and then release
Nortification Button.
Load Alkaline batteries.
Check the version
(Rev.1.00).
No display.
To Next Page
