Item Code No. Parts Name Specification Q R
AA EA
LOWER CASE B ASS'Y
10-1 6418 3880 LED button Z305 C340922-1 1 1 C
10-2 6418 3770 Open button Button Z305 C240728-1 1 1 C
10-3 6418 3690 Lower case B-Z305 C140364-1 1 1 X
10-4 6561 7320 Rubber foot Z305 C441692-1 2 2 X
10-5 6670 1380 Switch knob ass'y C441777*1 1 1 C
10-6 6418 3790 Battery switch knob Z305 C240730-1 1 1 X
10-7 6418 4250 Spring A-Z305 C441562-1 1 1 C
Z305-1 PCB ASS'Y
5-1 6511 0770 Battery spring K-L538AA C311380-1 1 1 X
5-2 6406 5030 Battery spring A-L517AA Y410305-1 1 1 X
5-3 6410 4560 Insulation seal Z449AA C413459-1 1 1 X
5-4 6418 4140 Tape F-Z305 C441476-1 1 1 X
5-5 3502 2082 Connector frame 305027000903000 1 1 B
5-6 6418 4150 Plate A-Z305 C441477-1 1 1 X
5-7 6418 3970 Battery plate B-Z305 C340958-1 1 1 X
5-8 6418 3980 Battery plate C-Z305 C340959-1 1 1 X
5-9 6418 3960 Battery plate A-Z305 C340957-1 1 1 X
5-10 6418 3990 Battery plate D-Z305 C340960-1 1 1 X
C67,C118 2845 6328 Electrolytic C ECA0JM471I 2 2 X
D2,D3,D43 7911 1806 Chip diode U2FWJ44N-TE12L 3 3 X
D4 2390 2401 Schottky diode U1GWJ44N-TE12L 1 1 X
D5,D42,D44,D45 2390 2926 Schottky diode 1SS294-TE85L 4 4 X
D10 2390 0623 Chip diode SB07-03C-TB 1 1 X
D12,D15 2390 2884 Chip diode SB20-03P-TD 2 2 X
D16 2390 2513 Schottky diode 1SS319-TE85L 1 1 X
EF4 3025 1848 EMI filter NFM51R10P107 1 1 X
EF5 3025 1911 EMI filter MEA8020T50R0T002 1 1 X
FS1 3632 0658 IC protector F1206A2R00FWTR 1 1 B
J1 3502 2075 Card connector (PCMCIA) 315027068040833 1 1 C
J2 3502 2096 RS232C connector 3560-16SR 1 1 C
J3 3502 2103 Connector 046239026001800S 1 1 C
J4 3502 2089 ROM connector MM20-64B2-1 1 1 C
J5 3502 2110 Connector 46239029001800 1 1 C
J10 3501 6538 Mini jack HSJ1169-012010 1 1 C
Q1,Q2 2254 0483 FET 2SK1829-TE85L 2 2 X
Q3,Q4 2250 1498 Chip transistor 2SA1518-TB 2 2 X
Q5,Q6,Q7,Q48 2259 2534 Chip transistor 2SC3912-TB 4 4 X
Q9,Q14,Q47 2254 0343 Chip transistor 2SK1588-T1 3 3 X
Q10,Q11,Q31,Q34, 2254 0490 FET 2SK1827-TE85L 8 8 X
Q41,Q46,Q50,Q52
Q12,Q15,Q16,Q30, 2259 2072 Chip transistor 2SJ317NY-TR 6 6 X
Q43,Q44
Q13 2254 0294 FET 2SJ179-T1 1 1 X
Q17 2254 0497 FET 2SK2159-T1 1 1 X
Q18,Q37 2254 0441 Chip transistor DTC114EKAT146 2 2 X
Q20 2251 0918 Chip transistor 2SB1119ST-TD 1 1 X
Q32 2254 0455 Chip transistor 2SJ344-TE85L 1 1 X
Q35 2259 2597 Digital transistor DTC114YKA-T146 1 1 X
Q49,Q51 2254 0336 FET 2SK1580-T1B 2 2 X
Q53 2254 0504 FET MMSF4P01HDR2 1 1 X
Q54 2254 0511 FET SI6426DQ-T1 1 1 X
R18,R19,R24 2725 1274 Network resistor CRB3A4E105JT 3 3 X
Notes: Q – Quantity used per unit R – A : Essential
R – Rank B : Stock recommended
C : Others
X : No stock recommended
AA :
EA :
CASIO 2 MB
CASIO 4 MB
— 79 —
