APPENDIX
APPENDIX
The numbers in parentheses indicate the pages where each part
is explained.
■ Camera
Front
Back
General Guide
1
Zoom Controller
(pages 68,156,157)
2
Shutter (page 61)
3
[ON/OFF] (Power)
(page 43)
4
Flash (page 71)
5
AF Assist/Self-timer Lamp
(pages 59, 76, 251)
6
Microphone
(pages 59, 82, 93)
7
Lens
7
4
5
3
2
1
6
8
Speaker (page 145)
9
Operation Lamp
(pages 43, 61, 251)
bk
[] (PLAY) Button
(pages 43, 201)
bl
[ ] (REC) Button
(pages 43, 201)
bm
Strap Hole (page 2)
bn
USB/AV Connector
(pages 205, 217, 232)
bo
Connector Cover
bp
Control Button
([S], [T], [W], [X])
bq
[BS] Button (page 97)
br
[SET] Button
bs
[MENU] Button (page 51)
bt
Monitor Screen (page 52)
8
9
bqbrbsbt
bk
bl
bm
bo
bn
bp
[SET]
[]
[
]
[
]
[
]
