122
Other Playback Functions (PLAY MENU)
To stop the slideshow, press [SET] or [MENU]. Pressing [MENU] stops the
slideshow and returns to the menu screen.
Adjust audio volume by pressing [2] and then press [8] or [2] during playback.
All button operations are disabled while the slideshow is transitioning from one
image to another.
The time required for transition from one image to another may be longer in the
case of an image that was not recorded with this camera.
You can replace the built-in slideshow background music with other music from your
computer.
Supported File Types:
PCM format (16-bit, monaural / stereo) WAV files
Sampling Frequencies: 11.025 kHz/22.05 kHz/44.1 kHz
Number of Files: 9
File names: SSBGM001.WAV to SSBGM009.WAV
Create the music files on your computer using the above names.
Regardless of which effect pattern you select, the music files you store in camera
memory are played back in name sequence.
1. Connect the camera to your computer (pages 142, 146).
If you plan to save the music files to the camera’s memory card, make sure the
card is loaded in the camera.
Effect
Select the effect you want.
Pattern 1 to 5: Plays background music and applies an image change effect.
Patterns 2 through 4 have different background music, but they all use the
same image change effect.
Pattern 5 can be used for playback of snapshots only (except for those that
are part of a CS group), and the “Interval” setting is ignored.
The currently selected image change effect setting is disabled automatically
in following cases.
When playing a slideshow for which “» Only” is selected for the “Images”
setting
When the interval setting is “MAX” or 1 second
Before and after playback of a movie
During CS group playback (Except the Pattern 1 effect)
Off: No image change effect or background music
Transferring Music from Your Computer to Camera Memory

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR400 and is the answer not in the manual?

Casio EXILIM EX-ZR400 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedJPG
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom12.5 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)9/8
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/2EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Flash off, Flash on, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Power source typeBattery, USB
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorBlack
Scene modesNight, Panorama
Image editingResizing, Rotating, Trimming
Photo effectsArt
White balanceAuto, Daylight, Fluorescent, Manual, Shade, Tungsten
Shooting modesMovie
Camera playbackSlide show
Self-timer delay2, 10 s
Battery life (max)5.8 h
Battery life (CIPA standard)515 shots
Cables includedAC, USB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
