125
Other Playback Functions (PLAY MENU)
4. Use [8] and [2] to select “Yes” and then press [SET].
The selected cut operation will take considerable time to complete. Don’t try to
perform any camera operation until the “Busy... Please wait...” message
disappears from the monitor screen. Note that a cut operation can take a long
time if the movie being edited is long.
IMPORTANT!
When you edit a movie, only the result is saved. The original movie is not retained.
An editing operation cannot be undone.
NOTE
A movie that is shorter than five seconds cannot be edited.
Editing of movies recorded with a different type of camera is not supported.
You will not be able to edit a movie if the amount of remaining memory capacity is
less than the size of the movie file you want to edit. If there is not enough memory
available, delete files you no longer need to free up more.
Splitting of a movie into two movies and splicing of two different movies into a
single movie are not supported.
You also can start a movie editing operation while the movie you want to edit is
playing back. When playback reaches a frame where you want a cut point to be,
press [SET] to pause playback. Next, press [2] to display the menu of editing
options. Perform editing using the same procedures as described above.
Procedure
[p] (PLAY) * Snapshot Screen * [MENU] *
p PLAY MENU” Tab * Lighting
You can use this setting to adjust the balance between bright areas and dark areas in
existing images in the range of 0 (no optimization) to +2 (bright).
NOTE
Correcting the lighting when shooting produces better results (page 101).
Altering the lighting of an image causes the original image and the new (altered)
version to be stored as separate files.
When you display an altered image on the camera’s monitor screen, the date and
time indicates when the image was originally recorded, not when the image was
altered.
Optimizing Image Brightness (Lighting)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR400 and is the answer not in the manual?

Casio EXILIM EX-ZR400 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedJPG
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom12.5 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)9/8
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/2EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Flash off, Flash on, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Power source typeBattery, USB
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorBlack
Scene modesNight, Panorama
Image editingResizing, Rotating, Trimming
Photo effectsArt
White balanceAuto, Daylight, Fluorescent, Manual, Shade, Tungsten
Shooting modesMovie
Camera playbackSlide show
Self-timer delay2, 10 s
Battery life (max)5.8 h
Battery life (CIPA standard)515 shots
Cables includedAC, USB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
