Casio EXILIM EX-ZR400 User Manual

170
Appendix
. Dropping and Rough Treatment
• Continued use of the camera after it is damaged by dropping or other
rough treatment creates the risk of fire and electric shock. Immediately
perform the following steps whenever any of the above symptoms are
present.
1. Turn off the camera.
2. If you are using the USB-AC adapter to power the camera, unplug the power
plug from the wall outlet. Also, remove the battery from the camera, taking
care to protect yourself against burn injury.
3. Contact your retailer or nearest CASIO authorized service center.
. Memory Cards
• Memory cards are small and present a risk of accidentally being
swallowed by infants and young children. Keep memory cards out of the
reach of infants and young children. If a memory card is ever swallowed
accidentally, contact a physician immediately.
. Precaution when Camera is On
• Do not touch the camera for long periods while it is on. The camera
becomes warm when on, and long term contact creates the risk of low-
temperature burns.
*
CAUTION
. USB-AC Adapter
• Misuse of the USB-AC adapter creates the risk of fire and electric shock. Make
sure you observe the following precautions.
– Never cover the USB-AC adapter or power cord with a quilt, blanket,
or other cover while it is in use, and do not use it near a heater. Doing
so can interfere with heat radiation and cause the area around them
to become hot.
– When unplugging from the wall outlet, never pull on the power cord. Grasp the
power plug and pull.
– Do not use detergent when cleaning the power cord (especially the plug), the
USB-AC adapter (especially the jack), or the USB cable (especially the plug).
– Insert the power plug into the wall outlet as far as it will go.
– Unplug the power plug from the wall outlet before leaving the camera
unattended for long periods, such as when leaving on a trip, etc.
– At least once a year, use a cloth or vacuum cleaner to clean any dust build up
on the prongs of the power plug and in the area around them.
*
WARNING
-
+
+
-
+

Casio EXILIM EX-ZR400 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	JPG
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	12.5 x
Focal length range	4.24 - 53 mm
Maximum aperture number	7.9
Minimum aperture number	3
Lens structure (elements/groups)	9/8
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 2EV (1/2EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction
Flash range (tele)	0.9 - 2.4 m
Flash range (wide)	0.4 - 4.7 m
Flash recharging time	5 s
Power source type	Battery, USB
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution	960 x 480 pixels
Display resolution (numeric)	460800 pixels
USB version	2.0
Product color	Black
Scene modes	Night, Panorama
Image editing	Resizing, Rotating, Trimming
Photo effects	Art
White balance	Auto, Daylight, Fluorescent, Manual, Shade, Tungsten
Shooting modes	Movie
Camera playback	Slide show
Self-timer delay	2, 10 s
Battery life (max)	5.8 h
Battery life (CIPA standard)	515 shots
Cables included	AC, USB
Bluetooth	No

Weight and Dimensions

Depth	28.6 mm
Width	104.8 mm
Height	59.1 mm
Weight	165 g
Weight (including battery)	205 g
