Page #189 background imageLoading...
Page #189 background image
189
Appendix
Display Messages
ALERT
The camera’s protection function may have activated
because camera temperature is too high. Turn off the
camera and wait until it cools down before trying to use it
again.
Battery is low. Battery power is low.
Can not find the file.
The image you specified with the slideshow “Images”
setting cannot be found. Change the “Images” setting (page
121) and try again.
Card ERROR
There is something wrong with the memory card. Turn off
the camera, remove the memory card and then reload it
into the camera. If this message re-appears when you turn
the camera back on, format the memory card (page 165).
IMPORTANT!
Formatting a memory card deletes all its files. Before
formatting, try transferring recoverable files to a
computer or some other storage device.
Check connections!
You are attempting to connect the camera to a printer while
the camera’s USB settings are not compatible with the USB
system of the printer (page 133).
Connecting to the
network
Camera power was turned off while image data was being
copied to a computer or other device using a FlashAir card
or an Eye-Fi card (pages 148, 150).
File could not be
saved because
battery is low.
Battery power is low, so an image file could not be saved.
Folder cannot be
created.
You are trying to record a file while there are already 9999
files stored in the 999th folder. If you want to record more,
delete files you no longer need (page 33).
LENS ERROR
This message appears and the camera turns off whenever
the lens performs some unexpected operation. If the same
message appears after you turn power back on, contact a
CASIO authorized service center or your original retailer.
LENS ERROR 2
The Anti Shake unit of the camera may be malfunctioning.
If the same message appears after you turn power back on,
contact your retailer or a CASIO authorized service center.
Load paper! The printer ran out of paper while printing.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR400 and is the answer not in the manual?

Casio EXILIM EX-ZR400 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedJPG
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom12.5 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)9/8
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/2EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Flash off, Flash on, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Power source typeBattery, USB
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorBlack
Scene modesNight, Panorama
Image editingResizing, Rotating, Trimming
Photo effectsArt
White balanceAuto, Daylight, Fluorescent, Manual, Shade, Tungsten
Shooting modesMovie
Camera playbackSlide show
Self-timer delay2, 10 s
Battery life (max)5.8 h
Battery life (CIPA standard)515 shots
Cables includedAC, USB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
