176
Appendix
. If the camera’s back lamp starts flashing red...
If the back lamp starts flashing red during charging, it means that further charging is
not possible for one of the reasons below. Perform the actions described below to
correct the problem and then try charging again.
Ambient temperature or the temperature of the battery is abnormally high
or low
Unplug the USB cable from the camera and wait for a while until the camera is within
the temperature range of 10°C to 35°C (50°F to 95°F), and then try charging again.
Safety timer activated
A battery that has not been used for a long time, certain types of computers, and
connection conditions can cause charging to take longer than normal. If charging
takes longer than about 6 hours, a safety timer will terminate it automatically, even if
the battery is not fully charged. If the battery has not been used for a very long time,
charging may terminate automatically after only about 45 minutes.
1) Using a battery that has not been used for a long time.
Disconnect and then reconnect the USB cable to resume charging.
2) Insufficient power supply when connected to computer
The camera can be charged only via a USB 2.0 standard USB port. Connect
directly to a USB port what supplies a current of 500mA.
For details about the power supply capacity of a computer’s USB port, contact the
manufacturer of the computer. Though disconnecting and then reconnecting the USB
cable will resume charging, you may need to do so repeatedly if the power supply
capacity of the computer is low.
Power Supply
Charging
If problems persist after you perform the above steps or if the battery fails to
charge after 6 hours, it could mean that the battery is faulty. Contact your nearest
CASIO authorized service center.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR400 and is the answer not in the manual?

Casio EXILIM EX-ZR400 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedJPG
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom12.5 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)9/8
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/2EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Flash off, Flash on, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Power source typeBattery, USB
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorBlack
Scene modesNight, Panorama
Image editingResizing, Rotating, Trimming
Photo effectsArt
White balanceAuto, Daylight, Fluorescent, Manual, Shade, Tungsten
Shooting modesMovie
Camera playbackSlide show
Self-timer delay2, 10 s
Battery life (max)5.8 h
Battery life (CIPA standard)515 shots
Cables includedAC, USB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
