Casio EXILIM EX-ZR400 User Manual

67
Recording Movies
IMPORTANT!
• Spending a long time using movie recording will cause the camera to become
slightly warm to the touch. This is normal and does not indicate malfunction.
• Shooting movies for long periods in areas where temperature is relatively high can
cause digital noise (dots of light) to appear in the movie image. A rise in the
camera’s internal temperature also may force movie recording to stop
automatically. If this happens, stop recording and allow the camera to cool down,
which should cause normal operation to resume.
• Using the camera’s built-in memory or certain types of memory cards can slow
down processing speed. Whenever possible use an Ultra High-Speed Type
memory card. Note, however, that not all operations can be guaranteed even if an
Ultra High-Speed Type memory card is used. Certain movie quality settings can
result in too much time being required to record data, which can result in breaks in
the image and/or audio during playback. If this happens, the Y will turn yellow on
the monitor screen.
NOTE
• Zoom operations are supported during movie recording (page 51). Zoom is
disabled during high speed movie recording. To use zoom for high speed movie
recording, perform the zoom operation before you press [0] (Movie) to start
recording.
• Both Single SR Zoom (page 54) and Multi SR Zoom (page 55) are disabled during
movie recording.
• The effects of camera movement in an image become more pronounced when you
shoot close up or with a large zoom factor. Because of this, use of a tripod is
recommended under these conditions.
• Except for High Speed Movie, Continuous AF (page 102) is performed during
movie recording while “AF” (Auto Focus) or “Macro” is selected for the “Focus”
setting.
• Face Detection is disabled during normal FHD and STD, and high speed movie
recording. Face Detection is enabled when shooting movies with Premium Auto
PRO (FHD and STD).
• The following functions do not support movie recording.
Blurred Background, All-In-Focus Macro, Triple Shot, Multi SR Zoom, some BEST
SHOT scenes
• The A, S, and M recording modes are not supported when shooting a movie, or
when using the “Prerecord (Movie)” and “For YouTube” BEST SHOT scenes. In
these cases, the recording mode is always P (Program Auto).

Casio EXILIM EX-ZR400 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.79 MP
Image sensor size	1/2.3 \
Image formats supported	JPG
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	12.5 x
Focal length range	4.24 - 53 mm
Maximum aperture number	7.9
Minimum aperture number	3
Lens structure (elements/groups)	9/8
Maximum focal length (35mm film equiv)	300 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 2EV (1/2EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction
Flash range (tele)	0.9 - 2.4 m
Flash range (wide)	0.4 - 4.7 m
Flash recharging time	5 s
Power source type	Battery, USB
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution	960 x 480 pixels
Display resolution (numeric)	460800 pixels
USB version	2.0
Product color	Black
Scene modes	Night, Panorama
Image editing	Resizing, Rotating, Trimming
Photo effects	Art
White balance	Auto, Daylight, Fluorescent, Manual, Shade, Tungsten
Shooting modes	Movie
Camera playback	Slide show
Self-timer delay	2, 10 s
Battery life (max)	5.8 h
Battery life (CIPA standard)	515 shots
Cables included	AC, USB
Bluetooth	No

Weight and Dimensions

Depth	28.6 mm
Width	104.8 mm
Height	59.1 mm
Weight	165 g
Weight (including battery)	205 g
