83
Using BEST SHOT
8. Press the shutter button the rest of the way down
and a slide cursor will appear on the monitor
screen. Slowly move the camera in the direction
indicated by the arrow on the screen until the
slide cursor reaches the other end of its
movement range (i.e. all the way to the right
when moving the camera to the right).
The camera will start composing the panorama image
internally when the slide cursor reached the other end
of the movement range.
Image composing also will start automatically if you
stop moving the camera during panorama shooting.
After you stop moving the camera, the message
“Busy... Please wait...” appears as the camera
processes the image. Wait until this message
disappears before using the camera. Image shooting
is disabled while the message is displayed.
NOTE
The following conditions are not compatible with Slide Panorama shooting.
Subject whose brightness is very different from that of its surroundings due to
artificial light, sunlight, etc.
Rivers, waves, waterfalls, or other subject with constantly changing patterns
Sky, beach, or other subject with continuous patterns
Camera too close to the main subject
Moving subject
Dark surroundings
Slide Panorama may stop part way through in the following cases.
Subject or camera movement
Camera movement that is too fast or too slow
Shooting a Slide Panorama image after half-pressing the shutter button to perform
Auto Focus may not produce the desired results if there are considerable
differences in the brightness, color, and/or focus of the individual images. If this
happens, try changing the focus position by focusing on a different subject, etc.
Since a Slide Panorama image is created by joining multiple images together, there
may be some roughness at the point where two images are joined.
Shooting under a flickering light source (such as fluorescent lighting) may result in
uneven brightness and/or coloring in the final Slide Panorama image.
The exposure and white balance when shooting Slide Panorama images are fixed
at the levels measured when you half-press the shutter button at the beginning of
the operation.
Shooting with this function causes the flash setting to change automatically to
? (Flash Off).
Slide cursor

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-ZR400 and is the answer not in the manual?

Casio EXILIM EX-ZR400 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels16.79 MP
Image sensor size1/2.3 \
Image formats supportedJPG
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom12.5 x
Focal length range4.24 - 53 mm
Maximum aperture number7.9
Minimum aperture number3
Lens structure (elements/groups)9/8
Maximum focal length (35mm film equiv)300 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/2EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed15 s
Flash modesAuto, Flash off, Flash on, Red-eye reduction
Flash range (tele)0.9 - 2.4 m
Flash range (wide)0.4 - 4.7 m
Flash recharging time5 s
Power source typeBattery, USB
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedH.264, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory52.2 MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution960 x 480 pixels
Display resolution (numeric)460800 pixels
USB version2.0
Product colorBlack
Scene modesNight, Panorama
Image editingResizing, Rotating, Trimming
Photo effectsArt
White balanceAuto, Daylight, Fluorescent, Manual, Shade, Tungsten
Shooting modesMovie
Camera playbackSlide show
Self-timer delay2, 10 s
Battery life (max)5.8 h
Battery life (CIPA standard)515 shots
Cables includedAC, USB
BluetoothNo
Weight and Dimensions IconWeight and Dimensions
Depth28.6 mm
Width104.8 mm
Height59.1 mm
Weight165 g
Weight (including battery)205 g
