Casio FE-700 MEX - Main Pcb Block (E287 Pol-1)

N
Item
Code No.
Name
Specification
Q
Price Code
R
1. Main PCB block
N
1
10102099
PCB ASSY/E287-1
E240736*3
1
DO
A
F4
30007777
FUSE
230.600
1
AE
A
IC1
21207349
IC/LINEAR
TL431CLPB
1
AG
A
IC11
10059678
LSI
UPD78052GC-A46-8BT
1
BO
A
IC15
10041544
LSI
UPD431000ACZ-70LL
1
BV
A
IC13
21051169
IC/MOS
TC74HC373AP
1
AG
A
IC14
21120714
EP-ROM
M27C1001-10/12F1
1
BI
A
IC16
21120837
IC/RESET
S-80845ANY-Z
1
AB
A
IC17, 19
21051218
IC/MOS
TC74HC08AP
2
AC
A
IC18, 20, 21
21051008
IC/MOS
TC74HC00AP
3
AC
A
IC2
20061326
LSI
UPD16312GB-3B4
1
AX
A
IC22
21051099
IC/MOS
TC74HC32AP
1
AC
A
IC26
21010189
IC/MOS
TC74HC138AP
1
AE
A
IC27
21120329
IC/LINEAR
MAX232N
1
AZ
A
IC3
21120007
IC/LINEAR
M5237L-T1
1
AF
A
IC4
21120840
IC/RESET
S-80819ANY-Z
1
AB
A
IC5
21141512
IC/LINEAR
BA10393
1
AC
A
IC7, 9, 10, 23-25
21120035
IC/MOS
TC74HC367AP
6
AF
A
IC8
21051015
IC/MOS
TC74HC245AP
1
AK
A
X1
25203445
OSCILLATOR/CRYSTAL
C-002RX(M90-76)
1
AD
A
X2
24088261
OSCILLATOR/CERAMIC
CST5.00MGW
1
AD
A
D30, 31, 35, 36
23153134
DIODE
SB10-04A3-BT
4
AB
B
D32, 33, 41-48
23010101
DIODE
1S2473-T-77-T
10
AA
B
D34, 51
23902828
DIODE
RB441Q-40T-77
2
AA
B
D37
23153095
DIODE
RB721Q-40T-77
1
AA
B
D38, 40, 49, 50
23153128
DIODE
1SR35-400AT-82
4
AA
B
D52
23153131
DIODE
1SS118TD
1
AA
B
D6-8,10-29
23153132
DIODE
1SS133T-77
23
AA
B
D9
23153133
DIODE
1SS244T-77
1
AA
B
DB1
23152857
BRIDGE/DIODE
S2VB20
1
AF
B
DCS1
30007623
CONVERTER/DC DC
DCS-298
1
AR
B
DCS2
30007616
CONVERTER/DC DC
PS10017
1
BI
B
Q1
22501554
TRANSISTOR
2SD1063(R,S)
1
AN
B
Q10
22501636
TRANSISTOR/DIGITAL
DTA143ZSA-TP
1
AA
B
Q14
22303902
TRANSISTOR
2SD1111-AA
1
AC
B
Q15
22304135
TRANSISTOR
2SD1853-AA
1
AC
B
Q2, 5, 13, 39, 43
22501330
TRANSISTOR
2SC1740S(QRSE)TP
5
AA
B
Q20, 21, 23, 25, 27,
29, 31, 33, 35, 37
22305261 TRANSISTOR 2SD965(P.Q.R)-TA 10 AB B
Q3
22501309
TRANSISTOR
2SD1804(T)
1
AF
B
Q38
22107186
TRANSISTOR
2SB926(T,U)-AA
1
AC
B
Q4, 12
22501323
TRANSISTOR
2SA933AS(QRS)TP
2
AA
B
Q44
22501633
TRANSISTOR
2SA1015(0.Y.GR)-TP
1
AA
B
Q6, 9
22501638
TRANSISTOR
2SA1704ST-AN
2
AB
B
Q7, 8, 11, 18, 22, 24,
26, 28, 30, 32, 34,
36, 40, 41, 42, 45
22501635 TRANSISTOR/DIGITAL DTC143ZSA-TP 16 AA B
SCR1
25002041
THYRISTOR
TF821M
1
AM
B
SW1
30007189
SWITCH/MT
JPM1030-0201
1
AC
B
ZD1
23152661
DIODE/ZENER
RD36EB1-T1
1
AA
B
ZD2, 6, 7
23153109
DIODE/ZENER
RD5.6EB2-T1
3
AA
B
ZD5
23153111
DIODE/ZENER
RD6.8EB3-T1
1
AA
B
ZD8
23153110
DIODE/ZENER
RD3.6EB2-T1
1
AA
B
ZD9-16
23152836
DIODE/ZENER
RD20EB2-T1
8
AA
B
ZD3
23153112
DIODE/ZENER
RD33EB1-T1
1
AA
B
BZ1
32402089
BUZZER
PKM22EPT-2001
1
AE
C
C1
28072658
CAPACITOR/ELECTROLYTIC
RE3-25V472M
1
AL
C
C11
28073575
CAPACITOR/ELECTROLYTIC
RE2-50V101M-T2
1
AB
C
