Casio FE-700 MEX - Button Block; Customer Display Block (E287-E2-2); Main Display Block (E287-E2-1)

N
Item
Code No.
Name
Specification
Q
Price Code
R
R24
RESISTOR/CARBON FILM
RD14J331T26
1
X
R25, 36
RESISTOR/CARBON FILM
RD14G242T26
2
X
R26,119
RESISTOR/CARBON FILM
RD14J221T26
2
X
R27, 40, 142
RESISTOR/CARBON FILM
RD14G103T26
3
X
R29, 30, 62-69, 111,
112, 116, 118, 132
RESISTOR/CARBON FILM RD14J102T26 15 X
R3
RESISTOR/CARBON FILM
RD14G102T26
1
X
R31, 39
RESISTOR/CARBON FILM
RD14J301T26
2
X
R32
RESISTOR/CARBON FILM
RD14J333T26
1
X
R33
RESISTOR/CARBON FILM
RD14J272T26
1
X
R34, 47, 87
RESISTOR/CARBON FILM
RD14J472T26
3
X
R35
RESISTOR/CARBON FILM
RD14G822T26
1
X
R37
RESISTOR/CARBON FILM
RD14G222T26
1
X
R38
RESISTOR/CARBON FILM
RD14J302T26
1
X
R141
RESISTOR/CARBON FILM
RD14J155T26
1
X
R41
RESISTOR/METAL FILM
RN14SFY2200T26
1
X
R42
RESISTOR/METAL FILM
RN14SFY1200T26
1
X
R138
RESISTOR/CARBON FILM
RD14J105T26
1
X
R48
RESISTOR/METAL FILM
ERG1SJ150P
1
X
R5
RESISTOR/METAL FILM
ERG12SJ101P
1
X
R51
RESISTOR/CARBON FILM
RD14J222T26
1
X
R6, 9, 11, 20, 21, 23,
46, 89, 91, 93, 95,
96, 98, 101, 102,
106, 107, 110, 114,
120, 137
RESISTOR/CARBON FILM RD14J103T26 21 X
R7
RESISTOR/CARBON FILM
RD14J201T26
1
X
R90
RESISTOR/CARBON FILM
RD14J334T26
1
X
R92
RESISTOR/CARBON FILM
RD14J684T26
1
X
SCREW 3X12 ZMC-3 1 X
CUSHION/CAPACITOR E440189-4 1 X
2. Main Display block
2
PCB ASSY/E287-E2-1
X
(Order by Main PCB)
DISP1
24088226
TUBE/DISPLAY
SH101MA
1
BP
B
CUSHION E412177-1 2 X
CN1
35015404
CONNECTOR
52045-2445
1
AD
C
CN2
10046393
CONNECTOR
52806-1310
1
AC
C
CN3
35022138
CONNECTOR
52806-1110
1
AA
C
3
62480508
CABLE/FFC JOINT A-E247
E440442-1
1
AK
C
4
30008040
CORE/FERRITE
SSC-40-12
1
AF
C
3. Customer Display block
DISPLAY ASSY E340991*4 1 X
5
10052414
PCB ASSY/E287-E2-2
E341197*1
1
CM
A
PCB/E287-E2-2 E341195-1 1 X
24088226 TUBE/DISPLAY SH101MA 1 BP B
CUSHION E440189-4 2 X
10046406 CONNECTOR 52807-1310 1 AA C
10046405 CONNECTOR 52807-1110 1 AC C
6
10046437
CABLE/FFC JOINT AE287
E440657-8
1
AD
C
7
10046438
CABLE/FFC JOINT BE287
E440657-9
1
AD
C
30008041 CORE/FERRITE SSC-33.5-12 1 AE C
8
62481785
CASE/REAR DISPLAY
E240511A-1
1
AH
C
N
9
10102105
PLATE/REAR DISPLAY
E240512-012
1
AI
C
PLATE/INSULATION E440781-1 1 X
4. Button block
10
62213988
CAP/L
E210964-1
2
AB
A
11
62214025
CAP/S
E311103-1
21
AA
A
12
62457250
BUTTON/1
E311792-1
1
AB
C
13
62457260
BUTTON/2
E311792-2
1
AB
C
- 55 -
