Recording Performances

EN-124

• The formats of audio data that can be played on this Digital Piano are shown below. (For playback

operations, see “Playing Back a Song from the Audio Recorder” (page EN-125).)

WAV format audio data

MP3 format audio data

File name extension .WAV

Format Linear PCM

Sampling frequency 44.1kHz

Bit depth 16bit

Channel Stereo

File name extension .MP3

Format MPEG-1 Audio Layer3

Sampling frequency 44.1kHz/48kHz

Bit rate 32 to 320kbps variable bit rate (VBR)

Channel Monaural/Stereo

Table of Contents4
Overview and Setup9
General Guide9
Touch Operation and Notation Used in this Guide12
Preparing a Power Supply13
Using an AC Adaptor13
Using Batteries15
Turning Power on or off19
Auto Resume20
Auto Power off20
Disabling Auto Power off20
Power on Alert21
Panel Lights off21
Adjusting Display Contrast22
Adjusting the Volume22
Using Commercially Available Headphones22
Outputting from the Speakers While Headphones Are Connected23
Headphone Mode23
Using a Commercially Available Microphone24
Operation Lock25
Options for Connecting to Smart Devices, Computers, and External Audio Devices26
Using the Included Wireless MIDI & Audio Adaptor27
Returning to Initial Factory Defaults27
Operations Common to All Modes28
Using the Touch Buttons and Touch Ring28
Touch Ring Basic Operation28
Setting the Sensitivity of the Touch Buttons and Touch Ring29
Setting the Volume of the Sound Made When the Touch Ring Is Used (Operation Click Volume29
Basic Operation for Contents of the Display30
Selecting Operation Items30
Navigating the Hierarchy of Setting Items33
The F Button Menu and FUNCTION Menu34
Using the F Button Menu34
Using the FUNCTION Menu36
Text Character Input38
Acoustic Settings for the Digital Piano and Playback of the Demo Songs41
Selecting the Piano Position Setting41
Listening to the Demo Songs42
Playing Notes with Different Tones44
Selecting a Single Tone44
Selecting a Tone by Number44
Selecting a Tone by Category45
Selecting a Tone with the Touch Buttons45
Selecting a Tone with the F Buttons46
Guitar and Bass Tones46
Sounding Two Different Tones at the same Time (Layer47
Layering Two Tones47
Unlayering the Keyboard48
Splitting the Keyboard between Two Tones (Split49
Splitting the Keyboard between Two Different Tones49
Changing the Split Point50
Unsplitting the Keyboard50
Changing Part Settings (Volume Level, Octave Shift, Tuning, Etc51
Applying Effects52
Using the Sound Mode Effects (Hall Simulator/Reverb and Surround52
Enabling or Disabling the Hall Simulator/Reverb and Surround Effects52
Specifying the Hall Simulator/Reverb Type53
Adjusting the Depth of the Hall Simulator/Reverb Effect54
Specifying the Surround Type54
Using DSP Effects55
Enabling or Disabling DSP55
Selecting a DSP Type56
Configuring DSP Settings56
Using Chorus (Chorus, Flanger, Short Delay60
Changing the Chorus Type60
Adjusting the Depth of the Chorus Effect60
Adjusting Brilliance61
Adjusting Acoustic Piano Sound Characteristics (Acoustic Simulator62
List of Acoustic Piano Sound Setting Items63
Using Microphone Effects64
Enabling or Disabling the Microphone Effect64
Specifying the Microphone Effect Type65
Changing Microphone Effect Settings66
Using the Mixer68
Adjusting the Volume Level, Stereo Pan and Effects for each Part68
List of Mixer Setting Items69
Changing the Sound During a Performance70
Using Pedals70
PEDAL UNIT Jack70
EXPRESSION/ASSIGNABLE Jack71
Enabling/Disabling the Pedal Operation for each Part (Upper 1/Upper 2/Lower74
Using the Knobs75
Using the Knobs to Change Parameters75
Changing the Function Assigned to a Knob76
Resetting the Parameters of the Functions Currently Assigned to the Knobs79
Using the CONTROL Button80
Selecting the Function Assigned to the CONTROL Button80
Using the Pitch Bend Wheel82
Changing the Pitch Bend Range82
Enabling/Disabling the Pitch Bend Wheel Operation for each Part (Upper 1/Upper 2/Lower83
Using the Metronome84
Starting or Stopping the Metronome84
Changing the Metronome Settings (Tempo, Beat, Pattern, Etc84
Using the Arpeggiator87
Enabling or Disabling the Arpeggiator87
Changing the Arpeggiator Pattern and Other Settings87
Saving and Recalling Performance Setups (Registration89
Saving a Setup Registration90
Changing a Registration Bank Name91
Recalling a Setup Registration92
Freeze Function93
Using a Pedal to Cycle through Multiple Setup Registrations (Sequential Recall94
Registration Memory Data95
Saving to an External Device96
Using the F Button Set97
Preset F Button Set List97
Editing an F Button Set98
Assigning a Function to an F Button (Creating a User F Button Set98
Changing the Name of an F Button Set103
Erasing an F Button Set105
F Button Function List106
Listening to Songs (SONG Mode109
Data Types of Playable Songs109
Playing Back MIDI Data or Audio Data110
Operations While Playing Back MIDI Data112
Sounding Metronome While Playing Back MIDI Data112
Adjusting the Volume Level of MIDI Data Playback (MIXER Settings112
Deleting a User Song112
Operations While Playing Back Audio Data113
Audio Center Cancel (Vocal Cut113
Adjusting the Volume Level or Effect Depth of Audio Data Playback (MIXER Settings113
Recording Performances114
MIDI Recorder and Audio Recorder Features114
Using the MIDI Recorder to Record Performances116
Recording with the MIDI Recorder116
Recording a Second Track over the First (System Track + solo Track120
Playing Back MIDI Recorder Songs121
Deleting a MIDI Recorder Song (Entire Song/Individual Tracks122
Items Reflected in Contents When Recording to the MIDI Recorder Song123
Recording a Performance with the Audio Recorder125
Recording Using the Audio Recorder125
Playing Back a Song from the Audio Recorder128
Deleting a Song from the Audio Recorder129
Adjusting Keyboard Sensitivity130
Changing Keyboard Response to Key Velocity (Touch Response130
Changing Touch Response Sensitivity130
Adjusting the Timing of Key Press to Sound (Hammer Response131
Adjusting the Hammer Response131
Adjusting the Timing of Key Release to Sound Damping (Key-Off Response132
Adjusting the Key-Off Response132
Changing the Pitch133
Changing the Pitch in Semitone Steps (Transpose133
Changing the Transpose Setting133
Fine Tuning a Pitch (Master Tuning133
Adjusting the Tuning Separately for each Part (Upper 1/Upper 2/Lower) (Part Fine Tune134
Changing the Pitch in Octave Units (Octave Shift135
Using Octave Shift Separately for each Part (Upper 1/Upper 2/Lower135
Changing the Scale Tuning (Temperament) of the Keyboard136
Changing the Scale136
Enabling or Disabling Piano Stretch Tuning137
Splitting the Keyboard for Duet Play138
Using the Duet138
Configuring Duet Settings140
USB Flash Drive141
Preparing a USB Flash Drive141
Supported USB Flash Drives141
Data Types Supported by the Digital Piano142
Connecting a USB Flash Drive to and Detaching It from the Digital Piano144
Formatting a USB Flash Drive145
Saving MIDI Files or Audio Files for Playback on Your Digital Piano to a USB Flash Drive146
Saving Digital Piano Data to a USB Flash Drive146
Loading USB Flash Drive Data into the Digital Piano's Internal Memory148
Deleting a USB Flash Drive File149
Renaming a USB Flash Drive File150
Configuring MIDI Settings151
Wireless Connections152
Configuring Wireless (Bluetooth) Connection Settings152
Checking the Wireless Connection Status152
Enabling and Disabling the Digital Piano's Wireless Function152
Notification Tones153
Connecting the Digital Piano with a Bluetooth Low Energy MIDI Device154
Connecting the Digital Piano with a Bluetooth Audio Device155
Pairing the Digital Piano with a Bluetooth Audio Device155
Deleting Bluetooth Audio Device Pairing Registration156
Using the Dedicated App158
About the App for Smart Devices (CASIO MUSIC SPACE158
Connecting with External Devices160
Playing Sound from a Smart Device on this Digital Piano (Bluetooth Audio Connection160
Playing Audio from a Smart Device or Other Bluetooth-Compatible Device on this Digital Piano160
Adjusting the Volume Level or Effect Depth of Bluetooth Audio (MIXER Settings160
Bluetooth Audio Center Cancel (Vocal Cut161
Using MIDI with a Connected Computer or Smart Device162
Connecting the Digital Piano with a Computer Via USB MIDI162
Connecting the Digital Piano with a Smart Device Via USB MIDI164
Outputting Digital Piano Notes through an Amplifier or Audio Equipment166
LINE out Jacks166
Connecting to Audio Equipment166
Connecting to a Musical Instrument Amplifier167
Deleting All Data in the Digital Piano's Internal Memory168
Troubleshooting169
Error Messages171
Reference173
Product Specifications173
Operating Precautions176
FUNCTION Menu Items178
DSP List186
Preset DSP List186
List of Effects in the DSP Modules189
Parameter List of DSP Module Effects191
Amp Cab Type List204
IR Type List206
Microphone Effects List227
Microphone Effect Type List227
List of Effects in the Microphone Effects Module228
Parameter List of Module Effects229
Arpeggiator List234
