Applying Effects
EN-53
To quickly switch the DSP effect type applied to a tone, select one of the “Preset DSPs” (DSP type
numbers 001 to 100) using the following operation:
1.
Perform the operation described in “Selecting a Single Tone” (page EN-41)
operation to select a tone.
2.
Select the “10 Effect” F button set. See “To change the F Button Set” (page
EN-32).
3.
Touch and hold the F4 button (DSP).
The “DSP” screen appears.
4.
Touch the ENTER button to display the “DSP TYPE” screen.
5.
Use the touch ring to select the type of DSP you want.
• “000 Tone” is the default DSP type for each tone.
• “001 Mono 1BandEQ” and after are “Preset DSPs” with their own names, such as equalizer or
compressor. See “Preset DSP List” (page EN-183) for details on the name and configuration of
each preset DSP.
The DSP of this Digital Piano consists of up to four modules (M1–M4) as shown in the figures below.
• In the case of a single module:
• In the case of four modules:
• Each module can contain various effects (equalizer, tremolo, compressor, etc.).
• Each DSP type has a specific module configuration (number of modules and effects inside). For
more information, see “Preset DSP List” (page EN-183).
When changing the DSP settings, adjust the parameters of the effects contained in each module.
Selecting a DSP Type
Configuring DSP Settings
To Next Page
