Casio Privia PX-S7000 User Manual

Operations Common to All Modes
EN-28
2. Touch the top or bottom of the touch ring.
Each touch of the touch ring moves the cursor ( ) between the dots.
3. Move the cursor ( ) to the item whose value you want to change.
For example, move the cursor ( ) to “Part name and tone number”.
4. Touch the left or right or trace along the touch ring.
The value at the cursor position (tone number in this example) changes.
• Instead of touching the left or right or tracing along the touch ring, you can use the value list that
appears when you touch the ENTER button. Refer to the following to use this method.
“Navigating the Hierarchy of Setting Items” (page EN-30)
“Using the F Button Menu” (page EN-31)
“Using the FUNCTION Menu” (page EN-33)
Part name and tone number

Casio Privia PX-S7000 Specifications

General

Touch Sensitivity	5 sensitivity levels, off
Sound Source	Multi-dimensional Morphing AiR Sound Source
Polyphony	256 notes
Key Action	Smart Hybrid Hammer Action Keyboard
Effects	Reverb, Chorus, DSP, Brilliance
Amplifiers	8W + 8W
Bluetooth	Yes (Audio & MIDI)
Pedals	3 (Damper, Soft, Sostenuto)
Display	LCD with backlight
USB Port	Yes (Type B)
Headphone Jack	2 (Stereo standard)
Dimensions	1340 x 242 x 102 mm (w/o stand, and music stand)
Weight	14.8 kg
Included Accessories	Music stand
Power Source	AC adapter
Number of Tones	400 built-in tones
