Casio XJ-UT312WN User Manual

3
Contents
Safety Precautions.......................................................... 7
Operating Precautions.................................................. 13
About the Light Source Unit.................................................................13
Projector Light Emission (XJ-UT Series) ..............................................13
Do not block light output or look directly into the lens!
(XJ-F Series) .........................................................................................14
Laser and High Temperature Precautions (See the label on the
projector) ..............................................................................................15
Other Precautions ................................................................................17
Precaution when Handling the Projector after Use ..............................19
Getting Ready................................................................ 20
Unpacking ............................................................................................20
Operation Flow to Projection................................................................20
General Guide ......................................................................................22
Key and Indicator Panel .......................................................................23
Back Terminals.....................................................................................24
Placing the Projector on a Desk or on the Floor ..................................25
Adjusting the Vertical Angle of the Projector ............................................................. 25
Setup Precautions ..................................................................................................... 26
Connecting with Another Device..........................................................27
Connecting a Computer ............................................................................................ 27
Connecting to a Video Device ................................................................................... 28
Outputting Audio from the Projector to Another Device............................................ 30
Connecting a Microphone (XJ-UT Series, XJ-F21XN, XJ-F211WN).......................... 31
Connecting to a Network with a LAN Cable (Network Models Only) ........................ 31
Connecting a Wireless Adapter (Network Models Only)............................................ 32
LOGO Terminal (Firmware Updates, User Logo Transfers) ....................................... 32
Connecting a Scientific Calculator (Network Models Only) ....................................... 33
SERIAL Terminal (Projector Control Using Commands)............................................ 33
USB Power ................................................................................................................ 34

Casio XJ-UT312WN Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	0.06 - 0.4 m
Vertical scan range	50 - 85 Hz
Horizontal scan range	15 - 91 kHz
Projection technology	DLP
Contrast ratio (typical)	20000:1
Screen size compatibility	50 - 110 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-5 - 5 °
Noise level	37 dB
Password protection	Yes
Light source type	Laser/LED hybrid
Service life of light source	20000 h
Focus	Manual
Offset	70 %
Fixed focal length	4.2 mm
Aperture range (F-F)	2.3 - 2.3
Full HD	-
Supported video modes	480i, 480p, 576i, 576p, 720i, 720p, 1080i, 1080p
Analog signal format system	NTSC, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
HDMI connector type	Full-size
Serial interface type	RJ-45, RS-232C
USB 2.0 ports quantity	2
S-Video inputs quantity	0
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables included	AC
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.23 W
Power consumption (typical)	170 W
Built-in display	No
Placement	Ceiling
Product type	Ultra short throw projector
Product color	White
Market positioning	Short throw
Cable lock slot type	Kensington
RMS rated power	16 W

Weight and Dimensions

Depth	333 mm
Width	338 mm
Height	141 mm
Weight	5900 g
