CASTLE TSM-21 - Router Operation

4.2 Router Operation
Router doesn’t cut pocket… Machine Clamps, Drills and releases:
□ Check Router Stop Switch for function or adjustment…………… 39 21.43
Router comes up and STAYS UP as soon as air is attached…..with Machine power OFF:
□ Check Router Solenoid for function or blockage…………………. 32 21.31
□ Unclog Router Solenoid…………………………………………….. 31 21.30
Router cuts pocket and STAYS UP, Drill doesn’t come out and Clamp doesn’t release:
□ Check Router Stop Switch for function or adjustment…………… 39 21.43
Router cuts pocket, Drill doesn’t come out and Clamp doesn’t release:
□ 43 21.51
□
Adjust internal Air Pressure…………………………...……………
21.90
□
Adjust the Router Feed Rate Valve...……………………..………
21.32
Check Drill Solenoid for function or blockage……………………..
Router advances too aggressively:
□
   ..............………………………………………
21.60
□
   Exhaust ……..………….…………
21.61
□
   ………………………...….…………
21.42
45
48
38
56
33
Castle Inc
TSM-21 Diagnostic Manual Parker/Humphrey Solenoids
Page 13 of 67
