CASTLE TSM-21 - Drill Operation

4.3 Drill Operation
Page Procedure
Drill DOES NOT come out, Machine Routs, Clamp DOES NOT release:
□ Check Drill Solenoid for function or blockage…………………….. 43 21.51
□ 41 21.50
Drill comes out and stays out as soon as air is attached…with Machine power OFF:
□
21.51
□ Adjust Air pressure, may be too low……………………………….. 56 21.90
□ Check Drill Solenoid for function or blockage …………………….. 43 21.51
□
□
Check Router Solenoid Exhaust port for blockage…………..……
48
21.61
□ Check Drill Solenoid Exhaust port for blockage…………….....…. 48
21.61
□ Adjust air pressure, Machine cycling too slowly………………….. 56 21.90
□ Bit mounted too deep into collet……………………………………. 36 21.41
Drill comes out and stops, Router cuts pocket and Clamp DOES NOT release:
Machine DOES finish cycle when carriage is pushed forward by hand:
Check Drill Solenoid for function / clean out drill solenoid
□□□ Unclog Drill Solenoid………………………………………………………………………………………………………………………………………………………………………………………………… 41
□□□□ Check drive cylinder for function..............................................…
Drill bit not completing pilot hole into Pocket:
45
□ Check for inconsistent web depth-See Router Stop Switch...,.....
29 21.22
Unclog Drill Solenoid……………………………………..............…
□
Check Bar Spring position.......................………………...…....….. 38 21.42
□
Check Drill Stop Switch………………………………......................
39 21.43
□ Check Router Stop Switch.......................……………………......... 39 21.43
□ Check Tooling, may be dull..........................................................
54 21.83
43
Castle Inc
TSM-21 Diagnostic Manual Parker/Humphrey Solenoids
Page 15 of 67
21.50
21.60
