Page Procedure
Pocket ragged or crooked:
□ Adjust Router Feed Rate, may be too fast………………………... 33 21.32
□ Check Clamp footpad, may need replacement…………………... 18 21.01
□ Check Tooling, may be dull………………………………………… 54 21.83
Pocket burned or smoking:
□ Adjust Router Feed Rate, may be too slow………………………. 33 21.32
□ Check Tooling, may be dull………………………………………… 54 21.83
Pocket misaligned with pilot hole:
□ Adjust Pilot Hole alignment…………………………………………. 49 21.72
□ Check Drill motor mounting………………………………………… 35 21.40
Pocket too close or too far from the edge of the stock, WEB adjustment:
□ Adjust Web with Router Stop Plate………………………………... 28 21.21
