Figure 11: Six Bay Charger, Side View and Power Cord
6. DC power connection for power supply (included).
7. DC power connection for optional 12V-24V kit.
8. DC plug (12V DC output).
9. Power supply (input 100V – 240V AC).
10. AC cord for power supply.
NOTE: Additional reference information for charge status LEDs is located on the bottom of the charger.
