Safe-E-Stop™
User Guide
Appendix F: Technical Data and Specifications PSD and MSD
*Refer to current datasheet at www.Cattron.com
Appendix G: Technical Data and Specifications Battery Charger
CHARGER MODEL
1PRT-8778-A001
1PRT-8779-A001
Dimensions (W x L x H)
101 x 137 x 81 mm
3.9 x 5.4 x 3.2 inches
509 x 148 x 94 mm
20.0 x 5.8 x 3.7 inches
Weight (Charger Only)
290 g / 0.64 lbs.
1.63 kg / 3.6 lbs.
Weight (Power Supply)
153 g / 0.34 lbs.
0.86 kg / 1.9 lbs.
Compatible Device
PSD-n-x-x
PSD-n-x-x
Operating Temperature
0° C – 32° C / 32° F – 104° F
0° C – 40° C / 32° F – 104° F
Storage Temperature
-20° C – 60° C / -4° F – 140° F
-20° C – 60° C / -4° F – 140° F
Power Supply Input
100V–240V AC / 50–60 Hz / 0.58A (max)
100V–240V AC / 50–60 Hz / 2.2A (max)
Charger Input
9V DC / 2.2A
12V DC / 7.0A (DC port)
12V / 7.0A - 24V / 3.5A (hardwire port)
Charger Output
4.2V DC / 1.3A
4.2V DC / 1.3A (each position)
Charge Rate
1.3A, 3 to 4-hour charge cycle
1.3A (each position) 3 to 4-hour charge
cycle
Approvals (Charger)
FCC / CEC / DOE
FCC / CEC / DOE
Approvals (Power Supply)
UL / FCC
UL / FCC
RoHS
Compliant
Compliant
