Setup mode 4 - 1
Chapter 4
Setup mode
Sensor setup
The N500 instrument can be used with different types and models of sensors. Therefore in
order to ensure correct measurement, it is necessary to preset exactly the type of sensitivity
of the sensors actually connected.
N.B.
Although the instrument can operate correctly with any combination of sensors, it
is advisable to connect sensors of the same type and model to the two channels.
1. Type of sensor:
Any one of the following possibilities can be selected:
– OFF : sensor not present (or else channel to be kept switched off)
– ACCEL : accelerometer
– VELOC : velocity sensor
– DISPLC : proximity sensor (non-contact)
N.B.
It is not possible to set both channels to OFF; at least one of the two channels
should be activated.
