Specification A - 1
Appendix A
Specification
- Instrument
- Dimensions: approx. 230 x 230 x 58 mm
- Weight: 1.75 kg
- Operating range
- Temperature: from -10° to +50° C
- Humidity in air: from 0 to 95% without condensation
- Power supply
- Rechargeable lithium battery, 6 Ah
- Charging time: less than 5 hours (from fully discharged battery)
- Power supply unit-battery charger for 100-240 V, 50/60 Hz (24 V, 1.5 A)
- Autonomy: over 8 hours with normal use of the instrument
- Display
– ¼ colour VGA TFT 320x240 – 5.7” back-lit
- Keyboard
- 28 keys, including 6 function keys
- Input channels
- 2 measuring channels (DC power supply max 5 mA, enabled or not enabled
automatically according to type of sensor)
- 1 photocell channel (speed and angular reference)
- Sensors which can be connected
- accelerometer
- velocity sensor
- proximity sensor
- general type, with max. signal 5 V-PP
- photocell 60-18.000 RPM
- high speed photocell
– Portable printer (optional)
– Dimensions: 146 x 88 x 65 mm
– Weight: 0.360 kg (without roll of paper)
– Printing on standard or adhesive paper
- Width of paper: 57.5 mm ± 1 mm
