CENTURION SYSTEMS WIZO-LINK - Removing an IO Link

page 25
www.centsys.com
When working with installed WiZos, locating the output WiZo would rely
on the installer keeping a record of which input WiZos activate the outputs of
WiZos that aren’t visible.
Start
1. Locate the I/O button on the output WiZo.
Start
1. Place the WiZo where the link will be removed into IO Link mode.
This will also put the whole network into IO Link mode.
a. PresstheI/Obuttonuntilaconrmationbeepisheard.
b. SincethenetworkisinI/OLinkmode,theIOLEDswillashrapidlyfor
‘has been linked’ and slowly for ‘no link’.
c. EnsurethattheOLEDisashingfastasthisindicatesthereisalinktoremove.
 IftheLEDisashingslowly,thismeansthereisnolinktoremove.
2. PressandholdtheI/Obuttonasecondtimeandwaituntilthereisaconrmation
beep. This indicates that the link has been broken.
2. Press and hold the button for a period exceeding 5 seconds, or until the WiZo beeps
twice.
3. Release the I/O button and the output WiZo will produce a rapid succession of beeps.
4. The WiZoisnowconguredinLatchmode.
5. Test the device link, by activating the input and
a. One press will activate the relay and keep it on.
b. Asecondpresswillswitchtherelay/outputo.
To change back to toggle mode, repeat the steps above.

An I/O link would be removed if no longer needed or if the I/O Link was created in error.
The I/O link is removed at the OUTPUT WiZo, not at the device where the input
is triggered (unless they are the same device).
Pre-step
1. Ensure that an I/O link exists between an input and an output.
2. Ensure that both WiZos are powered up.
• O LED will be OFF if there are no other output links associated with it
• O LED will be ON if one or more output links remain in place
At the same time, the [I LED] on the WiZo where the input was associated with
thisoutput,willstoprapidlyashing.Instead,itwill:
• Turn ON if the device has links to other outputs remaining in place
• Turn OFF if the device has no remaining links to other outputs on other
devices
QUICK START SECTIONSECTION 4
