SPECIFICATIONSSECTION 5
Thefollowingspecicationswerecorrectatthetimeofpublishingandmaybe
subject to change without notice.
TABLE 13
1. The current values can be used to determine current consumption for battery life backup calculations.
Supply Voltage Minimum Supply 11.5 Vdc
Maximum Supply 24 Vdc
Current Consumption
1
Average Current 30 mA @ 12Vdc
Peak Current 50 mA @ 12Vdc
Maximum Devices Devices per network 50
I/O Inputs / Device 1
Outputs / Device 1
Number of outputs
linkable by single
input
10
Number of inputs
linkable to single
output
10
Physical Data Unit Weight 65g
Dimensions 78mm W X 58mm D x 31mm H
Operating Temperature Degrees Celsius -15°C - 80°C
