QUICK START SECTIONSECTION 4

4.1. Getting Started
4.2. The WiZo User Interface
When the WiZos are removed from their packaging, it is important to remember the
following:
The WiZosarereadytobeused;theyhavejustnotbeenconguredoraddedtoa
network.Congurationiswhattheuser/installerneedstodo.
The WiZo interacts with the user by means of a combination of LEDs, tactile switches
and a buzzer.
Tactileswitchescomeinmanyshapes,sizes,coloursandaremadefromdierent
materials. They all have one thing in common, that is to make proper contact, it needs
rmforcetoensurethatthebuttonisseatedproperly,especiallywhenitneedstobe
held in one place for a period of time. Ensure that, during the setup process, when the
switchneedstobeheldforaperiod,thatrm,evenforceisapplied.
ThecombinationofLEDsandtactileswitcheswillenabletheinstallertocongure
the WiZo. To identify the various aspects of the WiZo interface, see the description in
the following tables;
Tampering with the manufacture of the device or modifying the manufacture of
the device will void the warranty.
Be sure to apply even, downward pressure onto the tactile switch.
Avoid excessive force or horizontal force as this may cause the surface


4.2.1. Power LEDs
LED LED State Description
Power On When illuminated, the LED indicates that the required power
has been applied to the PCB.
O No power has been applied to the WiZo.
TABLE 7
1. If the power LED does not illuminate, but other LEDS do, this indicates that the LED has malfunctioned.
It does not indicate a system error.
