8. Appendix
APPENDIXSECTION 8
G-ULTRA
External pull-down

D-Series
Controller
Possible Activations
• Trigger Open

• Gate Open / Closed
• Gate Opening / Closing
• Gate Standing Open
• Mains Failure
• Battery Low
• Multiple Collisions
RELAY 1 RELAY 2
GND IO1 IO2 IO3 IO4 NO NOCOM COMNC NC VDC
8.1. Wiring a G-ULTRA into a D-Series Controller via a WiZo
FIGURE 14
WiZo
WiZo
IN
IN
NO
NO
COM
COM
NC
NC
GND

+12VDC
TRG
TRG
GATE STATUS
GATE STATUS
