chapter 5000
page 83
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
This function is useful to understand if a traction problem is due to the encoder or not.
In case the truck stops or works with low speed with high consumption of current (and relevant alarm code shown
on the dashboard) it is possible to disable the encoder for some seconds, no longer, given that the logic unit cannot
control the motor any longer.
Do not work with this configuration.
SLIP CONTROL (MASTER connection number 3)
Select SLIP CONTROL ON or OFF and store the
parameter pressing OUT and then ENTER to confirm.
After that switch the truck OFF and ON.
COMPENSATION
SLIP CONTROL ON/OFF
Press ROLL
Press ROLL
until reaching ALARM menu
Press ENTER
Press ENTER
Press PARAM and SET
together
Press ENTER
* MENU *
SPECIAL ADJUST
* MENU *
HARDWARE SETTING
MAIN MENU
PARAM. CHANGE
MAIN MENU
ALARM
DESCRIPTION OF THE
ALARM CODE
With the SLIP CONTROL OFF push the
accelerator pedal slowly otherwise the motor
stands still.
DA2M2B C CE 1.13
48V 280A 00000
