BATTERY (MASTER connection number 3)
The control of the battery LED indication on the dashboard and the relevant reduction of speed are performed
by the MASTER of the traction logic unit.
Press ROLL and
PARAM together
Press ROLL
HOUR COUNTER RUNNING/ KEY ON
BATTERY CHECK ON
HYDRO KEY ON ON/OFF
STOP ON RAMP ON/OFF
AUX INPUT #1 EXCLUSIVE HYDRO
OPTION #1
CUT BACK SPEED
PEDAL BRAKING ANALOG/DIGITAL
SET TEMPERATURE ANALOG/DIGITAL/NONE
STEER TABLE OPTION #1
OPTION #2
Press ENTER
Press OUT
Press ENTER
Press ROLL
Press ENTER
SET POT BRK MIN ....V
SET POT BRK MAX ....V
SET BATTERY TYPE 48
ADJUST BATTERY ....V
MAX STEER RIGHT ....V
MAX STEER LEFT ....V
SET STEER 0-POS 2.5V
SET STEER RIGHT ....V
SET STEER LEFT ....V
THROTTLE 0 ZONE ....%
THROTTLE X ZONE ....%
THROTTLE Y ZONE ....%
ADJUSTMENT #02 1-9
ADJUSTMENT #01 1-9
MAIN CONT VOLT ....V
AUX OUTPUT VOLT ....V
Press ENTER
Scroll the parameters using ROLL and
save the new values pressing OUT and
then ENTER
Press OUT
* CONFIG. MANU *
SET OPTIONS
* CONFIG. MENU *
SET MODEL
ARE YOU SURE?
YES=ENTER NO=OUT
* CONFIG. MANU *
SET OPTIONS
* CONFIG. MANU *
ADJUSTMENTS
ARE YOU SURE?
YES=ENTER NO=OUT
DA2M2B C CE 1.13
48V 280A 00000
