chapter 5000
page 87
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
SET BATTERY TYPE: selects the nominal battery voltage
ADJUST BATTERY: adjusts the value displayed in the console to adapt it to the real value of the
battery (measured with a multimeter)
ADJUSTMENT #02 adjustment of the lowest value of charge of the battery
ADJUSTMENT #01 adjustment of the reset value of the battery indicator
ADJUSTMENT #01
ADJUSTMENT #02
0 45.70
1 45.98
2 46.22
3 46.51
4 46.75
5 47.04
6 47.33
7 47.57
8 47.81
9 48.38
CONSOLE VALUE
VOLT
0 49.20 49.10
1 49.48 49.39
2 49.73 49.58
3 50.02 49.87
4 50.26 50.11
5 50.54 50.35
6 50.83 50.64
7 51.02 50.83
8 51.26 51.27
9 51.80 51.55
CONSOLE VALUE VOLT
RESETTING
indicatore della batteria
