DESCRIPTION OF THE CONSOLE STANDARD MENU
AC2 LIFTING UNIT
The console can be connected to the lifting logic unit in two different ways:
1. Directly by means of an interface cable on the logic unit.
2. By connecting the console to another logic unit (traction or Mhyrio) and selecting the relevant connection
number as shown in the map here below.
In case the console is connected to the traction logic unit
It is the connection number of the traction logic unit.
CONNECTION NUMBERS
3 TRACTION MASTER
4 TRACTION SLAVE
5 PUMP
9 MHYRIO
11 DASHBOARD
Press ROLL and PARAM together
Press ENTER
Press ROLL, OUT and SET together
Press OUT
Press ENTER
to confirm
Press SET and select the connection number of the lifting logic unit
It is the connection number of the lifting unit.
Connected to the lifting logic unit
* CONFIG. MENU *
SET MODEL
CONNECTED TO
3
CONNECTED TO
5
ARE YOU SURE?
YES=ENTER NO=OUT
* CONFIG MENU *
SET MODEL
DA2M2B C CE 1.13
48V 280A 00000
AC2P2B D CE 1.06
48V 350A 00000
To Next Page
