CESAB C3E150 User Manual

chapter 5000
page 98
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
MAIN MENU
HEADING
PARAMETER
CHANGE
TESTER
SET MODEL
SET OPTIONS
ADJUSTMENTS
CONNECTED TO 5
HOUR COUNTER RUNNING/KEY ON
BATTERY CHECK ON/OFF
SET TEMPERATURE DIGITAL/ANALOG/
NONE
PROGRAM
VACC
STEER
TABLE
ALARMS
RESTORE
PARAMETER
SAVE
PARAMETER
VACC SETTING MIN/MAX
NOT AVAILABLE
CODE
h, N°, C°
DESCRIPTION OF THE CONSOLE STANDARD MENU
AC2 LIFTING UNIT MENU
ACCELER/DELAY 0-9
DECELER/DELAY 0-9
MAX SPEED UP Hz
MIN SPEED UP Hz
HzCUTBACK SPEED %
CUTBACK SPEED 2 %
1ST SPEED FINE Hz
2ND SPEED FINE Hz
3RD SPEED FINE Hz
4TH SPEED FINE Hz
AUX FUNCTION 1 %
HYD SPEED FINE Hz
MAXIMUM CURRENT A
AUXILIARY TIME sec
MOTOR VOLTAGE %
FREQUENCY Hz
ENCODER Hz
SLIP VALUE Hz
CURRENT RMS A
TEMPERATURE °C
MOTOR TEMPERATURE °C
ACCELERATOR V
SEAT SWITCH ON-OFF
CUTBACK SWITCH ON-OFF
CUTBACK SWITCH 2 ON-OFF
LIFTING SWITCH %
1ST SPEED SWITCH %
2ND SPEED SWITCH %
3RD SPEED SWITCH %
4TH SPEED SWITCH %
HYDRO SPEED REQ. %
VOLTAGE BOOSTER %
BATTERY VOLTAGE V
COS FI
BATTERY CURRENT A
BATTERY CHARGE %
SET BATTERY TYPE 48/72/80/96
ADJUST BATTERY ....V
THROTTLE 0 ZONE ....%
THROTTLE X POINT ....%
THROTTLE Y POINT ....%
ADJUSTMENT #04 ....°C
ADJUSTMENT #03 ....°C
ADJUSTMENT #02 1-9
ADJUSTMENT #01 1-9
