Cewe Prometer 100 - Page 58

Page 58 of 72
Prometer 100 User Manual
BGX501-943-R01
Click Connect and then select connection media as TCP/IP, communication type as DLMS. Select the
checkbox “Use TCP profile over Ethernet port.”
Enter the meter static IP information in Connection Address
Click OK.
Static IP is 172.16.13.5
Service port is 4059. It is fixed for DLMS
