APPENDIXPIÈCES DÉTACHÉESODRŽAVANJE
• Ugradnja filterske košare
Ponovno postavite košaru filtra na uređaj. Filtarska košara se poravnava s otvorom za
vodu i stavlja u uređaj za čišćenje. Stavite pokrovnu ploču vodeći računa da košara
filtera savršeno pristaje uz pokrovnu ploču.
7. After restarting, the machine will execute the corresponding cleaning
program according to the preset parameters
Note:
1. When using App, it needs to obtain Bluetooth use permission and
location permission of the mobile phone
2. App is suitable for ios14 and above, and Android 8.0 and above.
3. To obtain weather information in APP, you need to turn on Location
service.
When it is difficult for the machine climb
the wall, it cannot clean the waterline,
and it tilts seriously when climbing the
wall, solve the problems according to the
figure. If the machine climbs the wall
normally, the following operations are
not required. After removing the
adhesive, two top floating blocks are
attached to the machine. Carry out
installation according to (Figure 6-1).
Attention:
1. Before installation, ensure that there is no water in the bonding
position.
2. There is adhesive on the back of the top floating block. When installing
the top floating block to the big cover, the edges of top floating block must
be glued properly. After 24 hours, the machine can be put into the pool for
work.
12
VI. Installa�on of floa�ng blocks (op�onal)
Floating blocks
Figure 6-1
UGRADNJA PLUTAJUĆIH BLOKOVA (OPCIONALNO)
Ako se uređaj normalno penje uz stijenke
bazena, sljedeće radnje nisu potrebne. Kada je
uređaju teško penjati se uz stijenke bazena, on
ne može očistiti vodenu liniju i može se ozbiljno
nagnuti. Zadatke riješite prema slici. Nakon
uklanjanja ljepive trake, zalijepite dva gornja
plutajuća bloka na stroj. Provedite postavljanje
prema (Slika 6-1).
Pažnja:
1 • Prije postavljanja provjerite da nema vode
na mjestu lijepljenja.
2 • Na stražnjoj strani gornjeg plutajućeg
bloka nalazi se ljepilo. Prilikom postavljanja
gornjeg plutajućeg bloka na veliki pokrov,
rubovi gornjeg plutajućeg bloka moraju biti
pravilno zalijepljeni. Nakon 24 sata, uređaj
se može ponovno staviti u bazen za rad.
Slika 6-1
Plutajući blokovi
STANJE VODE U BAZENU
Napomena: Stanje vode u bazenu mora biti unutar sljedećih parametara:
• PH: 7,0-7,4
• Temperatura: 50 °F -95 °F (10 °C -35 °C )
• Sol: Max. 5000 ppm
• Klor: Max. 2 ppm
4.3.2 Take out the filter basket from the machine (Figure 4-3).
Figure 4-3
4.3.3 Cleaning of the filter basket
Rinse the dirt of the filter screen with clear water (Figure 4-4).
4.3.4 Installation of the filter basket
Reinstall the filter basket to the machine. The filter basket is aligned with
the water inlet and put into the cleaning machine. Put the cover plate on,
make the filter basket fit with the cover plate perfectly.
Figure 4-4
10
