• Installation of the filter basket
Reinstall the filter basket to the machine. The filter basket is aligned with the water inlet
and put into the cleaning machine. Put the cover plate on, make the filter basket fit
with the cover plate perfectly.
7. After restarting, the machine will execute the corresponding cleaning
program according to the preset parameters
Note:
1. When using App, it needs to obtain Bluetooth use permission and
location permission of the mobile phone
2. App is suitable for ios14 and above, and Android 8.0 and above.
3. To obtain weather information in APP, you need to turn on Location
service.
When it is difficult for the machine climb
the wall, it cannot clean the waterline,
and it tilts seriously when climbing the
wall, solve the problems according to the
figure. If the machine climbs the wall
normally, the following operations are
not required. After removing the
adhesive, two top floating blocks are
attached to the machine. Carry out
installation according to (Figure 6-1).
Attention:
1. Before installation, ensure that there is no water in the bonding
position.
2. There is adhesive on the back of the top floating block. When installing
the top floating block to the big cover, the edges of top floating block must
be glued properly. After 24 hours, the machine can be put into the pool for
work.
12
VI. Installa�on of floa�ng blocks (op�onal)
Floating blocks
Figure 6-1
INSTALLATION OF FLOATING BLOCKS (OPTIONAL)
If the machine climbs the wall normally, the
following operations are not required. When
it is dicult for the machine to climb the wall,
it cannot clean the waterline, and may tilt
seriously. Solve the problems according to the
figure. After removing the adhesive, stick the
two top floating blocks to the machine. Carry
out installation according to (Figure 6-1).
Attention:
1 • Before installation, ensure that there is no
water in the bonding position.
2 • There is adhesive on the back of the top
floating block. When installing the top
floating block to the big cover, the edges of
top floating block must be glued properly.
After 24 hours, the machine can be put
again into the pool for work.
Figure 6-1
Floating blocks
POOL WATER CONDITION
Remark: The pool water condition must be within following parameters:
• PH: 7.0-7.4
• Temperature: 50°F -95°F (10°C -35°C )
• Salt: Max. 5,000 ppm
• Chlorine: Max. 2 ppm
4.3.2 Take out the filter basket from the machine (Figure 4-3).
Figure 4-3
4.3.3 Cleaning of the filter basket
Rinse the dirt of the filter screen with clear water (Figure 4-4).
4.3.4 Installation of the filter basket
Reinstall the filter basket to the machine. The filter basket is aligned with
the water inlet and put into the cleaning machine. Put the cover plate on,
make the filter basket fit with the cover plate perfectly.
Figure 4-4
10
