9.0 Parts Lists & Schematics
33
Main Assembly – Front View, Parts list rev. “D”
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
1
5700
BACKGAUGE ASM.
1
2
E-3073-( )
SWITCH - START AND STOP
REF.
3
5712
LABEL - SHOCK HAZARD, COVER REM., ON/OFF
1
4
S-1864-2
CAPTIVE RETAINING DEVICE
2
5
K-480-3
FRONT GRILL
1
6
K-250-8
SPRING
2
7
K-249
LIFT SPRING BRACKET
1
8
KK-440-16
GUIDE BAR ASM
2
9
K-836-4
GUIDE ROD BRACKET
1
10
K-251-3
ROD - LIFT SPRING
1
11
EE-2889
CABLE ASSEMBLY - POWER
1
12
4629-1
SPRING - PRESSURE FOOT
6
13
KK-281-2
CUT STICK KNOCK OUT (S/N: 125781 & UP)
3
KK-281-5
CUT STICK KNOCK OUT (S/N: 125780 & BELOW)
14
E-1152-61
STANDOFF - 3/4"
4
15
A-4626-7
PRESSURE FOOT ASM.
3
16
S-1518-37
RETAINING RING
6
17
A-5847-1-6R
SPINDLE BLOCK ASM. - R.H.
1
18
A-5862-1-6R
SPINDLE BLOCK ASM. - L.H.
1
19
4693-1
PULLEY
1
20
S-706
BEARING
2
21
5859
SCALE - SPINDLE LOCATION
1
22
5858
INDICATOR
2
23
5856
SHAFT - SPINDLE BLOCK GUIDE
2
24
5710
ADJ. SCREW KNOB
2
25
16541-2
HYDRAULIC POWER UNIT ASM.
REF.
26
5716-2
GUARD - L.H.
1
27
5717-2
GUARD - R.H.
1
28
K-16-4
SPINDLE
1
29
K-57-19
CHIP CHUTE - CENTER
1
30
5711
ADJ. SCREW
2
31
H-6953-828
SCREW - 1/2-13 X 1-3/4 OVAL PT. SOC SET
1
32
H-6910-406
SCREW - 1/4-20 X 3/4 BUT. HD. CAP
6
33
H-6910-63203
SCREW - #6-32 X 3/8 BUT. HD. CAP
4
34
H-6938-408
SCREW - 1/4-20 X 3/8 SET
1
35
H-6918-814
SCREW - 1/2-13 X 1-3/4 SOC. CAP
2
36
H-6938-404
SCREW - 1/4-20 X 1/4 SOC. SET
4
37
H-6910-102403
SCREW - #10-24 X 3/8 BUT. HD. CAP
6
38
H-7321-12
WASHER - 3/4 USS FLAT
1
39
H-7327-8
WASHER - 1/4 MEDIUM LOCK
4
40
H-7327-16
WASHER - 1/2 MEDIUM LOCK
4
41
H-5239-12
NUT - 3/4 LIGHT FLEX LOCK
1
42
H-6424-8
NUT - 1/2 HEX JAM
5
43
H-7324-#10
WASHER - #10 INT. TOOTH
4
44
E-519
NUT - 1/2 CONDUIT LOCK
1
45
S-887
CONNECTOR - CABLE STRAIN RELIEF
1
46
H-7321-10
WASHER - 5/8 FLAT
1
47
S-1781-188
LABEL - POWER CONNECTION PROCEDURE
1
50
K-85
COVER - DRIFT HOLE
3
51
CD-4-2-1/2
DRILL - 1/4" X 2-1/2
3
CD-5-2-1/2
DRILL - 5/16" X 2-1/2
3
52
5841
SHIM - 26 GAGE
3
53
5841-1
SHIM - 20 GAGE
3
54
4687
DRILL DRIFT (NOT SHOWN)
1
55
4688
DRILL EASE STICK (NOT SHOWN)
1
56
S-1615
CORK - FOR DRILL CLEANER (NOT SHOWN)
1
57
W-130
3/16" HEX ALLEN WRENCH (NOT SHOWN)
1
58
W-137
5/32" HEX ALLEN WRENCH (NOT SHOWN)
1
59
W-141
1/8" HEX ALLEN WRENCH (NOT SHOWN)
1
60
KK-473-3
1 DOZEN WOOD DRILL BLOCKS
1
61
A-4950-2
DRILL SHARPENER/CHIP REMOVER (NOT SHOWN)
1
