9.0 Parts Lists & Schematics
35
Main Assembly – Upper Right View, Parts List REV. “C”
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
1
5739
WASTE BIN
1
2
41130
SERIAL PLATE
1
3
5886
HINGE
1
4
5870
HOOK - CHIP BAG
2
5
E-1172-4
SNAP IN BUSHING
1
6
E-968-4
CLAMP - 3/8" CABLE
3
7
S-1880
LABEL - OIL
2
8
K-2-24
SPINDLE BRACKET
1
9
K-478-3
BRACE - R.H. GUIDE
1
10
K-479-4
BRACE - L.H. GUIDE
1
11
5725
BACK COVER
1
12
5733
HOOD SUPPORT
1
13
S-1781-16
LABLE - CAUTION
2
14
5720-3
HOOD ASM.
1
15
S-2021
SPRING PLUNGER
1
16
K-836-4
GUIDE ROD BRACKET
1
17
K-780-2
SPINDLE ADJ. ROD
1
18
E-1172-11
SNAP IN BUSHING
1
19
K-1-33
FRAME
1
20
S-1818-2
THREADED COLLAR
1
21
5729-1
LABEL - FRONT PANEL
1
22
H-21S-187-0500
PIN - 3/16 X 1/2 ROLL
2
23
A-5878-1
CHIP CHUTE SWING ASM.
1
24
5715
JACK SCREW
1
25
5734
TABLE ASM.
1
26
5738
ADJUSTING SCREW
2
27
S-1602
KNOB - SPINDLE LOCK
2
28
S-1781-86
LABEL - DRILL DEPTH ADJ.
1
29
S-1684
LABEL - SPEED CONTROL
1
30
KK-289-34
STAND ASM.
1
31
AA-6098
BELT ADJ. ASM.
1
32
16075
SPACER - MOTOR BELT ADJ.
1
33
E-1600-69
MOTOR - SPINDLE, 60 HZ
1
E-1600-70
MOTOR - SPINDLE, 50 HZ
34
KK-265-4
MOTOR BRACKET ASM.
1
35
5857
PLUG
2
36
H-6910-83204
SCREW - #8-32 X 1/2 BUT. HD. CAP
8
37
H-6910-102404
SCREW - #10-24 X 1/2 BUT. HD. CAP
6
38
H-6910-102403
SCREW - #10-24 X 3/8 BUT. HD. CAP
1
39
H-6910-404
SCREW - 1/4-20 X 1/2 BUT. HD. CAP
4
40
H-6913-504
SCREW - 5/16-18 X 1/2 HEX HD. CAP
4
41
H-6918-606
SCREW - 3/8-16 X 3/4 SOC. HD. CAP
2
42
H-6918-610
SCREW - 3/8-16 X 1-1/4 SOC. HD. CAP
4
43
H-6918-608
SCREW - 3/8-16 X 1" SOC. HD. CAP
4
44
H-6951-612
SCREW - 3/8-16 X 3/4 NYLOC SOC. SET
2
45
H-6918-814
SCREW - 1/2-13 X 1-3/4 SOC. HD. CAP
2
46
H-7324-#8
WASHER - #8 INT. TOOTH
8
47
H-7324-#10
WASHER - #10 INT. TOOTH
6
48
H-7324-8
WASHER - 1/4 INT. TOOTH
4
49
H-7322-5
WASHER - 5/16" PLAIN
4
50
H-7327-16
WASHER - 1/2 MED. LOCK
2
52
H-6423-#10
NUT - #10-24 HEX
1
53
H-6433-8
NUT - 1/2-13 HEX JAM, L.H. THREAD
2
54
H-6424-8
NUT - 1/2-13 HEX JAM
1
55
H-6910-416
SCREW - 1/4-20 X 2" BUTTON HD.
REF
56
H-7324-8
WASHER - 1/4 INT. TOOTH
REF
57
H-6423-4
NUT - 1/4-20 HEX
REF
