Challenge EH-3D - Page 43

9.0 Parts Lists & Schematics
43
Power Panel Assembly – Parts List – EE-3256 Rev. C
NO.
PART NO.
DESCRIPTION OF ACCESSORIES
QTY
1
E-3257
PANEL - ELECTRICAL
1
2
E-2232-1
RELAY
1
3
E-2742-13
TRANSFORMER, 50VA - 230V PRIM./24V SEC.
1
4
E-1977-23
MOUNTING RAIL - TERMINAL BLOCK 5" LONG
1
5
E-3264-7
CIRCUIT BREAKER - TRIP 6A (CB1)
1
6
E-3264-5
CIRCUIT BREAKER - TRIP 4A (CB2)
1
7
E-3255
SWITCH - ON/OFF ELECTROMAGNETIC
REF
8
E-2068-8
TERMINAL BLOCK - 10GA FEED THRU
8
9
E-2068-3
TERMINAL BLOCK - GROUNDING
1
10
E-2070-1
END BLOCK - TERMINAL BLOCK
1
11
E-2507-2
FIXED BRIDGE - 2 POLE
1
12
E-1356-( )
MARKING STRIP - TERMINAL BLOCK
2
13
E-1214-51
CONNECTOR - 3/16 FULLY INS. Q.D.
2
14
E-1214-8
CONNECTOR - #10 INS. RING (16-22GA)
1
15
E-1214-49
CONNECTOR - 1/4" FULLY INS. Q.D. (16-14GA)
4
16
E-1214-65
CONNECTOR - 1/4" FULLY INS. Q.D. (18-22GA)
2
17
E-709-R
WIRE, #18 GA. RED MTW 82" TOTAL
1
18
E-849-R
WIRE, #16 GA. RED MTW 68" TOTAL
1
19
EE-2354-1
CABLE ASSEMBLY - SOLENOID
1
20
EE-3258
CABLE ASSEMBLY - SPINDLE MOTOR POWER
1
21
EE-3259
CABLE ASSEMBLY - FOOTSWITCH
1
22
S-1781-197
LABEL - GROUND SYMBOL, PRIMARY
1
23
S-1694
TYRAP (NOT SHOWN)
5
24
S-1694-6
TYRAP
4
25
H-6910-83203
SCREW, #8-32NC X 3/8" BUT HD CAP
2
26
H-7324-#8
WASHER, #8 INT. TOOTH
2
27
H-6910-102403
SCREW, #10-24NC X 3/8" BUT HD CAP
4
28
H-7324-#10
WASHER, #10 INT. TOOTH
4
